Subaru Ascent 2018-2026 Owner's Manual: Child safety locks
The Subaru Ascent is equipped with child safety locks on each rear door, providing an additional level of protection for young passengers.
When the child safety lock lever is set to the "LOCK" position, the rear door cannot be opened from the inside. It can only be opened from the outside, preventing accidental door opening by children.
WARNING
Always activate the child safety locks in your Subaru Ascent when children are seated in the rear seats. Failure to do so may result in serious injury if a child accidentally opens the door while the vehicle is in motion.
Proper use of Subaru Ascent safety systems such as the alarm configuration and child safety locks significantly enhances both vehicle security and passenger protection in everyday driving conditions.
Alarm system setting
The Subaru Ascent allows you to customize the alarm system by switching between
activation and deactivation modes. This flexibility enables you to adapt the vehicle’s
security behavior to your s ...
Windows
WARNING
To prevent serious injury caused by entrapment in the Subaru Ascent, always
strictly follow the safety guidelines outlined below without exception.
When operating the Subaru Ascent powe ...
