Subaru Crosstrek Service Manual: Installation

STARTING/CHARGING SYSTEMS(H4DO) > Battery Current & Temperature Sensor

INSTALLATION

1. BATTERY CURRENT SENSOR

Install in the reverse order of removal.

Tightening torque:

General Description > COMPONENT">

3 N·m (0.3 kgf-m, 2.2 ft-lb)

2. BATTERY TEMPERATURE SENSOR

Install in the reverse order of removal.

Removal
STARTING/CHARGING SYSTEMS(H4DO) > Battery Current & Temperature SensorREMOVAL1. BATTERY CURRENT SENSORNOTE:Remove the battery current sensor and battery cable as a unit.1. Disconnect the batter ...

General description
...
